User's Manual 508 Document #: LTRT-42060
Mediant 2600 E-SBC
To configure a logging filtering rule:
1. Open the Logging Filters Table page (Configuration tab > System menu > Logging
> Logging Filters Table).
2. Click Add; the following dialog box appears:
Figure 39-4: Logging Filters Table - Add Record Dialog Box
3. Configure a logging filter according to the parameters described in the table below.
4. Click Submit, and then save ("burn") your settings to flash memory.
Note: To configure the Syslog debug level, use the 'Debug Level' parameter (see
''Enabling Syslog'' on page 505).
Table 39-5: Logging Filters Table Parameter Descriptions
Parameter Description
Index
[LoggingFilters_Index]
Defines an index number for the new table record.
Note: Each table row must be configured with a unique index.
Filter Type
CLI: filter-type
[LoggingFilters_FilterType]
Defines the filter type criteria.
[1] Any (default)
[8] IP Group = Filters according to a specified IP Group ID listed
in the IP Group table
[9] SRD = Filters according to a specified SRD ID listed in the
SRD table
[10] Classification = Filters according to a specified
Classification rule listed in the Classification table
[11] IP-to-IP Routing = Filters according to a specified SBC IP-
to-IP routing rule listed in the IP-to-IP Routing table
[12] User = Filters according to a specified user, defined by
username or username@hostname in the Request-URI of the
SIP Request-Line. For example, "2222@10.33.45.201",
representing the following INVITE:
INVITE sip:2222@10.33.45.201;user=phone
SIP/2.0.
[13] IP Trace = Filters according to a specified IP network trace
wireshark-like expression. For a detailed description on
configuring IP traces, see ''Filtering IP Network Traces'' on page
509.
