User's Manual 602 Document #: LTRT-42060
Mediant 2600 E-SBC
Parameter Description
Diversion Header
[UseSIPURIForDiversio
nHeader]

[0] = 'tel:' (default)
 [1] = 'sip:'
[TimeoutBetween100An
d18x]
Defines the timeout (in msec) between receiving a 100 Trying response
and a subsequent 18x response. If a 18x response is not received within
this timeout period, the call is disconnected.
The valid range is 0 to 180,000 (i.e., 3 minutes). The default is 32000
(i.e., 32 sec).
[IgnoreRemoteSDPMKI]
Determines whether the device ignores the Master Key Identifier (MKI) if
present in the SDP received from the remote side.
 [0] Disable (default)

[1]
Enable
CLI: sdp-ecan-frmt
[SDPEcanFormat]
Defines the echo canceller format in the outgoing SDP. The 'ecan'
attribute is used in the SDP to indicate the use of echo cancellation.
 [0] = (Default) The 'ecan' attribute appears on the 'a=gpmd' line.
 [1] = The 'ecan' attribute appears as a separate attribute.
 [2] = The 'ecan' attribute is not included in the SDP.
 [3] = The 'ecan' attribute and the 'vbd' parameter are not included in
the SDP.
Note: This parameter is applicable only when the IsFaxUsed parameter
is set to 2, and for re-
INVITE messages generated by the device as result
of modem or fax tone detection.
Web/EMS: First Call
Ringback Tone ID
CLI: 1st-call-rbt-id
[FirstCallRBTId]
Defines the index of the first ringback tone in the CPT file. This option
enables an Application server to request the device to play a distinctive
ringback tone to the calling party according to the destination of the call.
The tone is played according to the Alert-Info header received in the 180
Ringing SIP response (the value of the Alert-Info header is added to the
value of this parameter).
The valid range is -1 to 1,000. The default is -1 (i.e., play standard
ringback tone).
Notes:
 It is assumed that all ringback tones are defined in sequence in the
CPT file.
 In case of an MLPP call, the device uses the value of this parameter
plus 1 as the index of the ringback tone in the CPT file (e.g., if this
value is set to 1, then the index is 2, i.e., 1 + 1).
Web/EMS: RTP Only
Mode
CLI: rtp-only-mode
[RTPOnlyMode]
Enables the device to send and receive RTP packets to and from remote
endpoints without the need to establish a SIP session. The remote IP
address is determined according to the
Outbound IP Routing table (Prefix
parameter). The port is the same port as the local RTP port (configured
by the BaseUDPPort parameter and the channel on which the call is
received).
 [0] Disable (default)
 [1] Transmit & Receive = Send and receive RTP packets.
 [2] Transmit Only= Send RTP packets only.
 [3] Receive Only= Receive RTP packets only.
Notes:
 To configure the RTP Only mode per trunk, use the
RTPOnlyModeForTrunk_x parameter.
 If per trunk configuration (using the RTPOnlyModeForTrunk_ID
parameter) is set to a value other than the default, the RTPOnlyMode
