Version 5.8 353 October 2009
SIP User's Manual 6. Configuration Parameters Reference
Parameter Description
if speech is detected (e.g., "hello") within approximately 2
seconds, the device completes the call transfer by releasing the
line; otherwise, the transfer is cancelled, the device sends a SIP
NOTIFY message with a failure reason in the NOTIFY body (such
as 486 if busy tone detected), and generates an additional hook-
flash towards the FXO line to restore connection to the original
call.
Message Waiting Indication (MWI) Parameters
Web: MWI Off Digit Pattern
EMS: MWI Off Code
[MWIOffCode]
Determines the digit code used by the device to notify the PBX that
there aren't any messages waiting for a specific extension. This code
is added as prefix to the dialed number.
The valid range is a 25-character string.
Web: MWI On Digit Pattern
EMS: MWI On Code
[MWIOnCode]
Determines the digit code used by the device to notify the PBX of
messages waiting for a specific extension. This code is added as
prefix to the dialed number.
The valid range is a 25-character string.
Web: MWI Suffix Pattern
EMS: MWI Suffix Code
[MWISuffixCode]
Determines the digit code used by the device as a suffix for 'MWI On
Digit Pattern' and 'MWI Off Digit Pattern'. This suffix is added to the
generated DTMF string after the extension number.
The valid range is a 25-character string.
Web: MWI Source Number
EMS: MWI Source Name
[MWISourceNumber]
Determines the calling party's phone number used in the Q.931 MWI
SETUP message to PSTN. If not configured, the channel's phone
number is used as the calling number.
Digit Patterns The following digit pattern parameters apply only to voice mail applications that use the
DTMF communication method. For the available pattern syntaxes, refer to the CPE Configuration
Guide for Voice Mail.
Web: Forward on Busy Digit
Pattern (Internal)
EMS: Digit Pattern Forward
On Busy
[DigitPatternForwardOnBus
y]
Determines the digit pattern used by the PBX to indicate 'call forward
on busy' when the original call is received from an internal extension.
The valid range is a 120-character string.
Web: Forward on No Answer
Digit Pattern (Internal)
EMS: Digit Pattern Forward
On No Answer
[DigitPatternForwardOnNo
Answer]
Determines the digit pattern used by the PBX to indicate 'call forward
on no answer' when the original call is received from an internal
extension.
The valid range is a 120-character string.
Web: Forward on Do Not
Disturb Digit Pattern (Internal)
EMS: Digit Pattern Forward
On DND
[DigitPatternForwardOnDN
D]
Determines the digit pattern used by the PBX to indicate 'call forward
on do not disturb' when the original call is received from an internal
extension.
The valid range is a 120-character string.
Web: Forward on No Reason
Digit Pattern (Internal)
EMS: Digit Pattern Forward
No Reason
[DigitPatternForwardNoRea
son]
Determines the digit pattern used by the PBX to indicate 'call forward
with no reason' when the original call is received from an internal
extension.
The valid range is a 120-character string.
