SIP User's Manual 374 Document #: LTRT-12801
MP-500 MSBG
Parameter Description
Web/EMS: MWI Server Transport
Type
[MWIServerTransportType]
Determines the transport layer used for outgoing SIP dialogs
initiated by the device to the MWI Server.
 [-1] Not Configured (default)
 [0] UDP
 [1] TCP
 [2] TLS
Note: When set to ‘Not Configured’, the value of the parameter
SIPTransportType is used.
Web: MWI Subscribe Expiration
Time
EMS: MWI Expiration Time
[MWIExpirationTime]
The MWI subscription expiration time in seconds.
The default is 7200 seconds. The range is 10 to 72000.
Web: MWI Subscribe Retry Time
EMS: Subscribe Retry Time
[SubscribeRetryTime]
Subscription retry time (in seconds) after last subscription
failure.
The default is 120 seconds. The range is 10 to 7200.
Web: Subscription Mode
[SubscriptionMode]
Determines the method the device uses to subscribe to an
MWI server.
 [0] Per Endpoint = Each endpoint subscribes separately -
typically used for FXS interfaces (default).
 [1] Per Gateway = Single subscription for the entire device -
typically used for FXO interfaces.
EMS: ETSI VMWI Type One
Standard
[ETSIVMWITypeOneStandard]
Selects the ETSI Visual Message Waiting Indication (VMWI)
Type 1 sub-standard.
 [0] = ETSI VMWI between rings (default)
 [1] = ETSI VMWI before ring DT_AS
 [2] = ETSI VMWI before ring RP_AS
 [3] = ETSI VMWI before ring LR_DT_AS
 [4] = ETSI VMWI not ring related DT_AS
 [5] = ETSI VMWI not ring related RP_AS
 [6] = ETSI VMWI not ring related LR_DT_AS
Note: For this parameter to take effect, a device reset is
required.
EMS: Bellcore VMWI Type One
Standard
[BellcoreVMWITypeOneStandard]
Selects the Bellcore VMWI sub-standard.
 [0] = Between rings (default).
 [1] = Not ring related.
Note: For this parameter to take effect, a device reset is
required.
