Chapter 5 Smart Battery 89
Smart Battery
Battery Introduction
The Autel Alpha aircraft comes standard with two MDH_10000_23700 smart batteries (hereafter
referred to as smart battery) as the power battery. This battery is a rechargeable lithium-ion
polymer (LiPo) battery and features high energy density and capacity. The smart battery can be
charged with a DF_CHARGER.
The battery charger is included as part of the aircraft kit. You do not need to purchase it
separately.
Battery Appearance
Table 5-1 Battery Appearance Details
1
Battery Limiting
Block
When installing the smart battery into the aircraft, ensure that
this side is facing up, insert the battery into the battery
compartment until the battery limiting block is locked by the
2 Power Button
When battery is powered off, short power the button for 1s to
check the battery level.
3
Used to display the current battery level of the smart battery in
normal situations.
