40 Chapter 3 Aircraft
26 Auxiliary Light
An LED auxiliary light. It is used to enhance the ambient
brightness of the landing area during the landing process,
improve downward visual sensing performance, and ensure
the safe landing of the aircraft.
27 Bottom Strobe
Emits high-intensity strobe lights to indicate the position of the
aircraft at night to avoid air traffic accidents.
28 Rear Support Legs
After the drone is folded, used to support the aircraft to avoid
damage to the bottom of the fuselage.
29
Downward Visual
Used to sense obstacles below, and to the left and right of the
aircraft and avoid collisions.
Warning
Do not disassemble the components that have been installed at the factory (except for the
components explicitly permitted in the description in this manual), otherwise, the product
warranty will be void.
Please prevent the 6 millimeter-
wave radars inside the fuselage from being blocked by
foreign objects. The six millimeter-
wave radars are located in the middle of the
forward visual sensing system, the rear visual sensing system, the side of the top shell (near
Auxi light), the bottom of the side visual sensing system, and near the fisheye lens at the
bottom shell of the fuselage, respectively.
Preparation Of Aircraft
Replacing Propellers
Propellers are consumable parts that require regular maintenance and replacement to ensure
the safe flight of the aircraft. The propellers are installed in the aircraft by default at the factory,
and reinstallation is not required. If the propellers are damaged (e.g., broken or damaged blades),
please replace them with new ones before a flight.
Keep body parts away from fan blades.
Tip
Aircraft propellers are wearable parts. If needed, please purchase them from Autel
Robotics.
The difference of propeller is marked on the blade. You can check the silk print on the blade
near the propeller center shaft.
