130 Chapter 6 Autel Enterprise App
The temperature of the measured target should be within 600
℃
. Over-temperature
measurements can cause burns and damage to the infrared detector.
Set Thermal Color
After tapping the " " icon, you can scroll up and down in the pop-up drop-down list to select a
color palette.
After selection, the images from the thermal camera will be displayed in the color style of the
selected color palette.
Set Infrared Shooting
Tap the " " icon to enter the "Camera Settings" interface and perform relevant settings. For
more information, see “6.8.1 Camera Function Area” in this chapter.
Set Radiometric Measurement Mode
Tap the " " icon or the " " icon to switch between radiometric measurement modes.
High gain mode (-20℃ to 150℃): This mode has higher radiometric measurement accuracy
but a smaller radiometric measurement range compared with the low gain mode.
Low gain mode (0℃ to 550℃): This mode has a larger radiometric measurement range but
lower radiometric measurement accuracy compared with the high gain mode.
FFC Calibration
Tap the " " icon to enable the FFC calibration function.
The radiometric measurement mode and FFC calibration functions can be used only after
the infrared radiometric measurement function is enabled in the camera settings.
Adjust the Infrared Zoom Factor
While shooting, tap the " " dynamic icon, and the infrared zoom factor setting window will pop
up. You can drag up or down to zoom in or out on the picture captured by the thermal camera,
so as to flexibly shoot objects at different distances.
The thermal camera of DG-L35T Gimbal support up to 16x digital zoom.
“Wide Angle Camera” Interface
On the main interface of the Autel Enterprise App, tap the " " icon in the corner of the "Wide
Angle Camera" preview interface, or tap the " " icon after entering the "Zoom Camera"
interface or “Thermal Camera” interface, to enter the "Wide Angle Camera" full-screen interface.
