42 Chapter 3 Aircraft
3. Remove and replace the entire propeller module, ensuring that the screw holes of the
propeller clamp matches the screw holes on the motor.
4. Screw down to tighten the propeller clamp.
5. After replacement, check again that the propellers matches the corresponding motors.
Replacing The Propellers On Front Arms
1. Flip the aircraft and place it on a level surface. Please protect the rear lens from any
scratches or damage.
2. Before replacement, confirm that the propellers have the same half-circle markings as the
motors.
3. Use the screwdriver to unscrew the 2 fixing screws.
4. Remove and replace the entire propeller module, ensuring that the screw holes of the
propeller clamp matches the screw holes on the motor.
5. When installing these front arm propellers, please place the propeller with silk print facing
downward (towards the top of the fuselage).
6. Screw down to tighten the propeller clamp.
7. After replacement, check again that the propellers matches the corresponding motors.
Install the Propellers
The propellers can rotate at a maximum speed of 6000 RPM. Please operate with caution.
Before each flight, make sure that all propellers are in good condition. If there are aged,
damaged, or deformed propellers, please replace them before the flight.
Before each flight, make sure that all propellers are mounted correctly and securely.
Stay away from rotating propellers or motors to avoid injuries.
Before testing the aircraft on the ground, make sure that the propellers are removed.
Fold/Unfold The Arms
Before using the aircraft, place it on a level ground. Unfold the front and rear arms. After the
arms are fully unfolded, you will hear a clicking sound, indicating that the arm locking button has
securely locked the arms, and the arms cannot be folded at this point.
