112 Chapter 6 Autel Enterprise App
The X-axis is the physical output of the command stick, and the Y-axis is the logical output of the
command stick. That is, the X-axis represents the movement generated by the current command
stick move, and the Y-axis represents the actual response strength of the current aircraft.
When the coefficient is 0.2, the slope of the curve increases gradually, which is convenient for
fine-tuning; when the coefficient is 0.7, the slope of the curve gradually decreases, and the
aircraft responds strongly when the command stick is slightly moved. Tap "Reset EXP
Parameters" to reset the EXP parameters.
Connect to Aircraft
Connect to aircraft: If the remote controller is currently not connected to the aircraft, tap
"Connect to aircraft", and then double-click the power button of the aircraft according to the
pop-up notification to complete the frequency pairing between the remote controller and the
aircraft. For more information, see “4.9 Frequency Pairing With the Remote Controller” in
Chapter 4.
Cancel: If the remote controller is currently connected to the aircraft, tap "Connect to aircraft",
and then tap “Cancel” in the pop-up window to disconnect the remote controller from the
aircraft.
Image Transmission Settings
In the sidebar of the “Settings” interface, tap the " " icon to enter the "Image Transmission
Settings" interface, where you can set the image transmission mode, transmission frequency
band, and split screen effect, as shown below.
"Image Transmission Settings" Interface
Set Image Transmission Mode
Tap the drop-down list of "Image Transmission Mode" and select “Smooth” or “HD” according to
your needs. Once selected, the remote controller will receive and display the image transmission
screen at the selected resolution.
