Chapter 8: Maintenance 187
3 Remove the outer droplet sleeve from the SIT by turning the SIP retainer
counterclockwise.
; Tip Hold the sleeve as you turn the retainer. The outer sleeve might fall
out as the retainer is loosened.
4 Remove the flat red or white Loader seal.
5 Install the black rubber O-ring in place of the Loader seal.
To order a replacement, see page 212.
6 Install the Bal seal, the SIP retainer, outer droplet sleeve, and tube guide
retainer.
See steps 3 through 6 on page 177 for instructions.
SIP retainer
outer droplet sleeve
Loader seal
