22 BD FACSCalibur Instructions for Use
Power Controls
The power switch on the right side of the cytometer does not completely shut off
instrument power. To shut off all power, use the switch in back of the instrument
(Figure 1-10). If you are using a power transformer, use the main power switch
on the transformer (Figure 1-11).
Figure 1-10 Instrument main power switch (115 VAC)
Figure 1-11 Transformer main power switch (230 VAC)
Main power switch
Connector for
GPIO cable
Connector for optional
BD FACS Loader cable
