This section of MC6 User Manual presents all measurements and genera-
tions/simulations that MC6 is capable of performing. No matter which of the
available main functions you use in MC6, the connections presented here ap-
ply.
Settings in Meter and Calibrator are saved, so the next time you measure,
generate or simulate something, the previous settings are available as de-
faults.
(
*
In Calibrator also the additional information row settings for all measure-
ments/generations/simulations are saved for future needs. However damping,
resolution and alarms are active for the current session only.
*
)
When you use Documenting Calibrator and select an instrument for cali-
bration, the instrument's settings (Quantity, Port etc.) are inherited to the
Calibrator.
Respectively, when creating a new instrument in Documenting Calibrator,
the settings in Calibrator's sub-windows are used as default settings for the
new instrument's input and output.
Notes.
For HART and Fieldbus instrument specifics, see Part 7,
Communicator.
For information on External Devices (Pressure and Tempera-
ture Controllers) used together with Calibrator and Document-
ing Calibrator, see Part 9, Additional Information.
Note.
In this manual, when presenting each measurement/gener-
ation/simulation there is a picture with highlighted active termi-
nals. The highlight for possible optional connections is lighter.
Connections to instruments are included if it requires special
attention. See, e.g. Current Generation (Source or Sink) on
page 24.
Next…
Measurements on page 17
Generations/Simulations on page 22
Meter in part 3
Calibrator in part 4
Documenting Calibrator in part 5
Data Logger in part 6
Communicator in part 7
Additional Information in part 9
