ATOMLAB 960 MEDICAL SPECTROMETER ASSEMBLY AND STAND OPERATION 2-1
2. Assembly and Uptake Stand Operation
Figure 2.1. The Atomlab 960 MCA Uptake Stand.
COMPUTER SHELF
PANEL PC
KEYBOARD
PRINTER
PRINTER SHELF
POWER CORD
BASE
CASTER LOCK
POWER SWITCH
WELL COUNTER
IN RECESS
COLLIMATOR COLUMN
RELEASE / LOCK
COLLIMATOR ARM HANDLE
COLLIMATOR ARM
ROTATION RELEASE
COLLIMATOR
LOCK KNOB
TARGET LED
HANDLE
COLLIMATOR
HANDLE
NECK PHANTOM
CALIBRATION FIXTURE
