1 Lock Switch
Move the switch down to lock the control panel and up to unlock it. Locking the panel lets
you prevent any unintended changes to settings or accidental streaming interruptions.
2 Audio Controls
Rotate the audio control knobs clockwise or counterclockwise to increase or decrease the
audio levels. Monitor the audio levels on the audio station LCD touchscreen.
3 LCD Assist Touchscreen
The side panel 5” LCD touchscreen lets you access all the settings for your camera,
plus displays your slate or a focus page with indicators to help you gauge perfect focus.
This allows multiple people such as camera assistants, sound recordists and other crew
members to work quickly with the camera on set.
4 Assist Station Buttons
The buttons on the assist station let you turn the status display on or off, access the focus
page, open the slate and more.
Display
Press the display button to cycle through the meters heads up display, the codec and
resolution heads up display, and clean feed.
TIP Holding down the display button for 3 seconds will dim the touchscreen. Press
any button on the assist station to turn it back on.
Lens
Press the lens button to cycle through the 1st AC display options, such as:
1 Maximized view with lens name and serial number metadata, exposure and focus
indicators.
2 Minimized view with focus indicator overlay.
3 Clean view with no overlays.
Press the display button to return the status display view.
Slate
Press to access the slate feature. Here you can enter clip metadata for shooting and
production use. Press again to close the slate settings.
Audio
Not currently active.
Stream
Once streaming has been set in your camera’s streaming setup settings, press and hold the
stream button on the assist station to start and stop streaming.
Menu
Press the ‘menu’ button labeled with the elipsis icon to open the menu settings. Press again
to close the menu.
Record
Press the record button to start recording a clip and press again to stop.
15URSA Cine Overview
