Neutral Density Filter Settings
ND Number Stops Fraction
clear 0 1
0.6 2 1/4
1.2 4 1/16
1.8 6 1/64
2 Power Switch
Power your URSA Cine by moving this switch to the ‘on’ position. Power off by moving the
switch to the ‘off’ position.
3 Settings Wheel
Set this wheel’s function by adjusting the switch located next to the wheel. The three switch
options are ‘headphone,’ ‘monitor’ and ‘iris’.
Headphone
When set to ‘headphone’, the settings wheel will adjust headphone audio levels. Rotatethe
wheel upwards to increase volume, and downwards to decrease.
Monitor
When set to ‘monitor’, the settings wheel adjusts audio levels on your URSA Cine’s built in
monitor speaker. The speaker is located on the outside of the LCDmonitor door and can be
used to monitor audio without headphones. Rotate the wheel upwards to increase volume, and
downwards to decrease. This function is disabled while recording from the camera’s internal
microphone to prevent unwanted feedback.
Iris
When set to ‘iris’, the settings wheel is used to adjust the aperture of compatible lenses.
Rotating the wheel downwards opens the iris, and turning the wheel upwards closes the iris.
These directions mimic the operation of aperture on adjustable still and cinema lenses.
4 Menu Wheel
When ‘status text’ is turned on for your URSA Cine’s EVF output, you can use the menu
wheel to navigate many of the head up display features usually accessed via the LCD
touchscreen.
Simply press the menu wheel as you would a button to access your URSA Cine’s head
up display on URSA Cine EVF. While the menu wheel is active, turn the wheel to select
features such as LCDmonitor options, frame rate, ISO, white balance and tint. Press the
wheel to confirm selections and make additional changes. Use the ‘back’ button next to
the wheel to cancel. You can also use the back button to move up a menu level, or exit
the menu completely if you’re at the top level. The menu will automatically close after one
minute of inactivity.
For more information on setting status text and the controls available, see the ‘touchscreen
controls’ and ‘monitor settings’ sections of this manual.
5 Lock
Toggle this switch to lock all of the controls on the forward control panel to prevent them
from being accidentally adjusted while shooting. Move this switch to the lower position to
lock, and the upper position to unlock.
66Control Buttons
