1 2
Unscrew the metal plugs from one end of each
rod and keep them somewhere safe as you will
need to screw them back on shortly.
Rotate URSA Cine EVF Bracket Rod Mount’s
thumbscrews counter clockwise to allow
enough room for the rods to slide through their
respective holes.
3
4
Tighten the thumbscrews to secure the rods. You will notice there is an adjustable top rod
mount attached to the front of URSA Cine’s top
handle. Loosen the rod clamps on each side and
insert the rods of the assembled EVF arm.
You can now screw the plugs back onto each rod and tighten the clamps. Avoid over tightening.
53Blackmagic URSA Cine EVF
