173 S850 Operation & Maintenance Manual
DIAGNOSTIC SERVICE CODES (CONT'D)
Service Codes List (Cont’d)
CODE DESCRIPTION CODE DESCRIPTION
T9002 Service tool output ‘C’ error ON W3252 ACS (AHC) tilt actuator short to battery
T9003 Service tool output ‘C’ error OFF W3253 ACS (AHC) lift handle / pedal short to ground
T9102 Service tool output ‘D’ error ON W3254 ACS (AHC) tilt handle / pedal short to ground
T9103 Service tool output ‘D’ error OFF W3255 ACS (AHC) lift handle / pedal short to battery
T9202 Service tool output ‘E’ error ON W3256 ACS (AHC) tilt handle / pedal short to battery
T9203 Service tool output ‘E’ error OFF W3257 ACS (AHC) lift actuator reduced performance
T9302 Service tool output ‘F’ error ON W3258 ACS (AHC) tilt actuator reduced performance
T9303 Service tool output ‘F’ error OFF W3259 ACS (AHC) lift actuator wrong direction
W3260 ACS (AHC) tilt actuator wrong direction
W3204
ACS (AHC) no communication to Bobcat
controller
W3261 ACS (AHC) handle lock short to ground
W3223 ACS (AHC) calibration required W3262 ACS (AHC) handle lock short to battery
W3224 ACS (AHC) calibration performed W3263 ACS (AHC) pedal lock short to ground
W3225 ACS (AHC) actuator calibration failed W3264 ACS (AHC) pedal lock short to battery
W3231 ACS (AHC) tilt actuator W3265 ACS (AHC) sensor supply voltage out of range
W3232 ACS (AHC) tilt actuator wiring W3266 ACS (AHC) battery voltage out of range
W3233 ACS (AHC) tilt handle wiring W3267 ACS (AHC) switch flipped while operating
W3234 ACS (AHC) tilt actuator not in NEUTRAL W3268 ACS (AHC) lift handle information error
W3235 ACS (AHC) tilt handle / pedal not in NEUTRAL W3270 ACS (AHC) right drive handle short to ground
W3236 ACS (AHC) lift actuator W3271 ACS (AHC) right drive handle short to battery
W3237 ACS (AHC) lift actuator wiring W3274 ACS (AHC) left joystick X-axis out of range
W3238 ACS (AHC) lift handle wiring W3275 ACS (AHC) interrupted unswitched power
W3239 ACS (AHC) lift actuator not in NEUTRAL W3276 ACS (AHC) CAN joystick information error
W3240 ACS (AHC) lift handle / pedal not in NEUTRAL W3277 ACS (AHC) remote control information error
W3241 ACS (AHC) no communication W3297 ACS (AHC) controller programmed
W3249 ACS (AHC) lift actuator short to ground W3905 Left joystick X-axis not in NEUTRAL
W3250 ACS (AHC) tilt actuator short to ground W4005 Right joystick X-axis not in NEUTRAL
W3251 ACS (AHC) lift actuator short to battery W4007 Right joystick Y-axis not in NEUTRAL
