31 S850 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION (CONT’D)
Right Panel (Standard Key Panel)
Figure 14
This machine may be equipped with a Standard Key
Pa
nel [Figure 14].
1. Key Switch: Used to turn the loaders electrical
system on and off, and to start and stop the engine.
2. Selectable Joystick Controls (SJC) Control
Pattern Switch (Option): Press the top to select
‘ISO’ Control Pattern; bottom to select ‘H’ Control
Pattern.
