66 S850 Operation & Maintenance Manual
HYDRAULIC CONTROLS (CONT’D)
Hydraulic Bucket Positioning
This machine may be equipped with Hydraulic Bucket
P
ositioning.
The function of hydraulic bucket positioning is to keep the
b
ucket at the same approximate angle as the lift arms are
raised.
Figure 79
Press the top of the BUCKET POSITIONIN
G switch (Item
1) [Figure 79] on the left switch panel to engage the
bucket positioning function. The amber light in the switch
will tur
n on. Press the bottom of the switch to disengage.
The amber light will turn off.
Bucket positioning functions only during upward lift cycle.
