197 S850 Operation & Maintenance Manual
(S850) LOADER SPECIFICATIONS (CONT’D)
Performance
Engine
Rated Operating Capacity 1792 kg (3950 lb)
with 200 Pound Frame Mounted
Counterweight Kit
1860 kg (4100 lb)
with 300 Pound Frame Mounted
Counterweight Kit
1882 kg (4150 lb)
with 400 Pound Frame Mounted
Counterweight Kit
1928 kg (4250 lb)
Tipping Load 3583 kg (7900 lb)
Operating Weight 4540 kg (10008 lb)
Breakout Force - Lift 3145 kg (6933 lb)
Breakout Force - Tilt 3164 kg (6975 lb)
Push Force 2874 kg (6336 lb)
Travel Speed
- Low Range / High Range 0 - 11,4 km/h (0 - 7.1 mph) / 0 - 19,8 km/h (0 - 12.3 mph)
Make / Model Kubota® / V3800-DI-TE3 Tier 3
Fuel / Cooling Diesel / Liquid
Horsepower
- ISO 9249 EEC / SAE J1349 Net
- ISO 14396 Gross
- SAE J1995 Gross
65,6 kW (88.0 hp) @ 2400 rpm
67,6 kW (90.6 hp) @ 2400 rpm
68,6 kW (92.0 hp) @ 2400 rpm
Torq ue
- ISO 9249 EEC / SAE J1349 Net
- SAE J1995 Gross
310,3 N•m (228.8 ft-lb) @ 1600 rpm
315,0 N•m (232.3 ft-lb) @ 1600 rpm
Low Idle rpm 1250 - 1400
High Idle rpm 2525 - 2650
Number of Cylinders 4
Displacement
3,8 L (230 in
3
)
Bore / Stroke 100 mm / 120 mm (3.94 in / 4.72 in)
Lubrication Gear Pump Pressure System with Filter
Crankcase Ventilation Open Breathing
Air Cleaner Dry replaceable paper cartridge with separate safety element
Ignition Diesel - Compression
Air Induction Turbo-Charged
Engine Coolant Propylene Glycol / Water Mixture
Starting Aid Air Intake Heater - Automatically activated as needed in RUN position
