18 S850 Operation & Maintenance Manual
MACHINE SIGNS (DECALS) (CONT’D)
Pictorial Only Safety Signs
Safety signs are used to alert the equipment operator or
maintenance person to hazards that may be encountered
in the use and maintenance of the equipment. The
location and description of the safety signs are detailed in
this section. Please become familiarized with all safety
signs installed on the machine / attachment.
Vertical Configuration
Horizontal Configuration
The format consists of the hazard panel(s) and the
avoidance panel(s):
Hazard panels depict a potential hazard enclosed in a
safety alert triangle.
Avoidance panels depict actions required to avoid the
hazards.
A safety sign may contain more than one hazard panel
and more than one avoidance panel.
NOTE: See the numbered MACHINE SIGNS
(DECALS) on Page 16 and MACHINE SIGNS
(DECALS) (CONT’D) on Page 17 for the
machine location of each correspondingly
numbered pictorial only decal.
1. High Range Speeds (7184346)
This safety sign is located in the operator cab on loaders
equipped with a seat belt with 3-point restraint.
HITTING OBSTRUCTIONS AT HIGH RANGE SPEEDS
CAN CAUSE SERIOUS INJURY OR DEATH
Fasten shoulder belt for additional restraint when
operating at high range speeds.
W-2754-0908
2. Hot Pressurized Fluid (7169699)
This safety sign is located on the engine coolant tank cap.
HOT PRESSURIZED FLUID CAN CAUSE
SERIOUS BURNS
• Never open hot.
• OPEN SLOWLY.
W-2755-0908
HAZARD
PANEL
AVOIDANCE
PANEL
HAZARD
PANEL
AVOIDANCE
PANEL
