INSTRUMENT PANEL IDENTIFICATION
Overview
Figure 7
The left panel [Figure 7] is described in more detail.
(See Left Panel (Earlier Models) on Page 26.) or (See
Left Panel (Later Models) on Page 28.)
Figure 8
The right panel [Figure 8] is described in more detail.
(See Right Panel (Standard Key Panel) on Page 31.) or
(See Right Panel (Keyless Start Panel) on Page 32.) or
(See Right Panel (Deluxe Instrumentation Panel) on
Page 33.)
Figure 9
The left (Item 1) and right (Item 2) [Figure 9] switch
panels are described in more detail. (See Left Switch
Panel on Page 35.) and (See Right Switch Panel on Page
35.)
Figure 10
The left and right side lower panels [Figure 10] are
described in more detail. (See Left Side Lower Panel on
Page 36.) and (See Right Side Lower Panel on Page 36.)
P-90668E
P-90212M
Standard Key
P-85285C
P-90819L
Keyless Start Deluxe Instrumentation
P127108A
1
2
P-85282
P-85267D
