84 S850 Operation & Maintenance Manual
STARTING THE ENGINE (CONT’D)
Deluxe Instrumentation Panel
AVOID SERIOUS INJURY OR DEATH
• Engines can have hot parts and hot exhaust gas.
Keep flammable material away.
• Do not use machines in atmosphere containing
explosive dust or gases.
W-2051-0212
Perform the PRE-STARTING PROCEDURE. (See PRE-
STARTING PROCEDURE on Page 77.)
Figure 115
Set the engine speed control to the idle position
[Figure 115].
NOTE: Loaders with a Deluxe Instrumentation Panel
ha
ve a permanent, randomly generated
Master Password set at the factory. Your
loader will also be assigned an Owner
Password. Your dealer will provide you with
this password. Change the owner password
to one that you will easily remember to
prevent unauthorized use of your loader. (See
Changing The Owner Password on Page 178.)
Keep your password in a safe place for future
needs.
NOTE: The Password Lockout feature can be used to
allow starting of the loader without a
password. (See Password Lockout Feature on
Page 179.)
Figure 116
Turn the key switch to RUN (Item 2) [Figure 116]. The
indicator lights on the left ins
trument panel will come ON
briefly and the Instrument Panel / monitoring system will
do a self test.
Use the numeric keypad (Item 1) [Figure 116] to enter
the password.
Figure 117
The machine will cycle the air intak
e heater automatically
based on temperature. The engine preheat icon (Item 1)
will be ON and the cycle time remaining (Item 2)
[Figure 117] will show in the data display.
When the engine preheat icon goes OFF, turn the key
s
witch to START (Item 3). Release the switch when the
engine starts and allow it to return to the RUN position
(Item 2) [Figure 116].
