29 S850 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION (CONT’D)
Left Panel (Later Models) (Cont’d)
* This manual contains a table with Service Code descriptions. (See DIAGNOSTIC SERVICE CODES on Page 167.)
REF. NO.
DESCRIPTION FUNCTION / OPERATION
12 RIGHT TURN SIGNAL (Option) Indicates right turn signals are ON.
13 DIESEL PARTICULATE FILTER
(DPF) / DIESEL EXHAUST FLUID
(DEF)
Not used.
14 SHOULDER BELT Instructs operator to fasten shoulder belt when operating in high range.
Remains lit while in high range.
15 HYDRAULIC SYSTEM
MALFUNCTION
Hydraulic system malfunction or failure. (See Service Codes*)
16 FUEL Fuel level low or sensor error.
17 DIESEL EXHAUST FLUID (DEF)
LEVEL
Not used.
18 FUEL GAUGE Shows the amount of fuel in the tank.
19 LIGHTS Press once for FRONT work lights and REAR taillights. (Left green
LED lights.) Press a second time to add REAR work lights. (Left and
right green LEDs light.) Press a third time to turn all lights off. (Left and
right green LEDs off.)
Press and hold 5 seconds to display software version in display screen.
20 AUTO IDLE Not used.
Move cursor to the left inside the DISPLAY SCREEN when using
certain INFORMATION button menus.
21 AUXILIARY HYDRAULICS without
high-flow option
Press once to activate the auxiliary hydraulic system. (Left green LED
lights.) Press a second time to deactivate the system.
AUXILIARY HYDRAULICS with
high-flow option
Press once to activate the auxiliary hydraulic system. (Left green LED
lights.) Press a second time to engage the HIGH-FLOW auxiliary
hydraulics. (Left and right green LEDs light.) Press a third time to
deactivate auxiliary hydraulics. (Left and right green LEDs off.)
Move cursor to the right inside the DISPLAY SCREEN when using
certain INFORMATION button menus.
22 INFORMATION Cycles through (after each button press):
• Hourmeter (On startup)
• Engine rpm
• Battery voltage
• Drive response menu
• Steering drift compensation menu
• Maintenance clock (Press and hold 7 seconds when displayed to
reset the maintenance clock.)
• Service codes*
23 TRACTION LOCK OVERRIDE Functions only when the seat bar is raised and the engine is running.
Press once to unlock the brakes. Allows you to use the steering levers
or joystick(s) to move the loader forward or backward when using the
backhoe attachment. (See TRACTION LOCK OVERRIDE in this
manual.) Press a second time to lock the brakes.
24 PRESS TO OPERATE LOADER Press to activate the BICS™ when the seat bar is down and operator is
seated in operating position. Button will light.
25 PARKING BRAKE (Standard on all
loaders)
Press the top to engage the Parking Brake. Press the bottom to
disengage. (See PARKING BRAKE in this manual.)
31 of 210
