Rig Up and Rig Down
Canrig Drilling Technology Ltd. 4-3
4. Move the Catwalk so the ramp end aligns with the setback distance marker.
22.5 29 62 20.5 97.32 273
23 29 62 20.5 97.32 269
23.5 29 62 20.5 97.32 264
24 29 62 20.5 97.32 259
24.5 29 62 20.5 97.32 254
25 29 62 20.5 97.32 249
25.5 29 62 22.5 97.32 243
26 29 62 22.5 97.32 301
26.5 29 62 22.5 97.32 292
27 29 62 22.5 97.32 291
27.5 29 62 22.5 97.32 286
28 33 62 22.5 97.32 280
28.5 37 62 25 18.32 338
29 37 62 25 18.32 333
29.5 37 62 25 18.32 328
30 37 62 26 18.32 323
30.5 37 62 26 18.32 318
31 37 62 26 18.32 312
31.5 37 62 26 18.32 306
32 41 62 26 18.32 366
32.5 41 62 26 18.32 361
33 41 62 29 18.32 355
33.5 41 62 29 18.32 350
34 41 62 29 18.32 344
34.5 41 62 29 18.32 338
35 41 62 29 18.32 332
Table 4-1: PC3000-26 Standard Configurations (Continued)
PC3000-26 Standard Configurations
Sub-floor
Height (ft)
Ramp (ft)
Pocket
(in)
Lift Arm
Length (ft)
Lift Arm
Mount (in)
Setback
Distance (in)
