Manual Operation
[C U R R E N T M E A S C A L I B R A T I O N
]
A P P L Y L O A D I N G A N D P R E S S[ E N T E R ]
S E T L O A D I N G C U R R E N T =
6
. 7 0 0 A
A C T U A L O U T P U T C U R R E N T= 0. 0 0 0 0 _ A
[ 2 ]
Figure 3-144
8. Press “
” to perform the 12A calibration. When the cursor stops at position [3] as
shown in Figure 3-145, set the Electronic Load to draw 12.00A current. Enter the current
read by the ULTRASTAB SATURN (DVM) and press “ ” to confirm it.
[C U R R E N T M E A S C A L I B R A T I O N]
A P P L Y L O A D I N G A N D P R E S S[ E N T E R ]
S E T L O A D I N G C U R R E N T = 1 2
. 0 0 0 A
A C T U A L O U T P U T C U R R E N T= 0. 0 0 0 0 _ A
[ 3 ]
Figure 3-145
9. Press “
” to do the 36.00A calibration. When the cursor stops at position [4] as
shown in Figure 3-146, set the Electronic Load to draw 36.00A current. Enter the current
read by the ULTRASTAB SATURN (DVM) and press “ ” to confirm it. Using the
calibration values obtained, the system will calculate the calibration factor for the high
current range.
[C U R R E N T M E A S C A L I B R A T I O N]
A P P L Y L O A D I N G A N D P R E S S[
E N T E R ]
S E T L O A D I N G C U R R E N T = 3 6 . 0 0 0
A
A C T U A L O U T P U T C U R R E N T= 0. 0 0 0 0
_ A
[ 4 ]
Figure 3-146
10. The current calibration is done when the above actions are completed. To save the
calibrated values, press “ ” and a confirmation screen will appear as shown in
Figure 3-147. Press “ ” or turn the “Rotary” (
) knob to set SAVE=YES and press
To Next Page
