Chroma A620028 - Page 178

Programmable DC Power Supply (with Solar Array Simulation) 62000H Series
Operating & Programming Manual
5-8
a. SETTING : The network card is being set.
b. CONNECTING : The network card is connecting.
c. NONE_CONNECT : The network is not connected.
d. CONNECTED : The network is connected.
e. MODULE_ERR : The network card setting is wrong.
Once the setup is complete, the panel will update and show the network settings and clear the
status message.
STEP 4:
Save the settings and return to the panel main screen.
Procedure for setting DHCP = OFF on Chroma DC Source 62000H
STEP 1:
Set the IP, GATEWAY and SUBNET MASK parameters manually when DHCP=OFF.
If the Site LAN parameters are not known, contact the network administrator and request the
settings for the network parameters.
The SUBNET MASK and GATEWAY can be input directly into the
62000H. The IP Address can be set with one on the same domain but
different from the PC. For instance, if the PC’s settings are: IP:
10.1.7.100, Mask: 255.255.254.0, and Gateway: 10.1.7.254, set IP:
10.1.7.101, Mask: 255.255.254.0 and Gateway: 10.1.7.254 for the
62000H.
STEP 2:
Press
to go to APPLY and set to YES to confirm sending out the settings.
STEP 3:
The screen will display the network setting status with one of the messages listed below:
a. SETTING : The network card is being set.
b. CONNECTING : The network card is connecting.
c. NONE_CONNECT : The network is not connected.
d. CONNECTED : The network is connected.
e. MODULE_ERR : The network card setting is wrong.
Once the setup is complete, the panel will update and show the network settings and clear the
status message.
STEP 4:
Save the settings and return to the panel main screen.
