Manual Operation
3-31
V
= 6 0
.
0 0 _
V I = 1 0.
0 0
A M S T O F F
0
. 0 0 0 0
V
0 .
0 0 0 0 A
0 .
0 W
Figure 3-48
3.3.3.4.2 Setting SYSTEM SETUP for Series
The operation of POWER ON STATUS in [SYSTEM SETUP] during series operation is the
same as for a single unit except the output voltage will increase based on the number of units
connected in series. For example, if there are 2 sets of 62150H-600S in series, the
maximum output voltage that can be set is 1200V, and the maximum output current is 25A, as
shown in
Figure 3-49 below:
[S Y S T E M S E T U P
]
A P G V S E T
=
N O N E
A P G I S E T
=
N O N E
A P G V M E A S
= N O N E
A P G I M E A S
=
N O N E
B U Z Z E R
= O N
P O W E R O N S T A T E S
=
U S E R D E F I N I T I O N
_
V
=
1 2 0 0
.
0 0 V I
=2 5
. 0 0 0
A O U T P U T = O F F
Figure 3-49
It will return to single unit mode once the POWER ON STATUS is set in
series mode. The POWER ON STATUS automatically sets the output
voltage and current to 0 and OUTPUT to OFF.
3.3.3.4.3 Setting OUTPUT SETUP for Series
The V LIMIT MAX in [OUTPUT SETUP] in the MASTER unit in a series connection will
increase based on the number of units connected in series. The set voltage is indicated by
ΣV LIMIT: MAX for easy identification as shown in Figure 3-50 below. The setting range of ΣV
SLEW RATE will also increase based on the number of units connected in series.
