Chroma A620028 User Manual

Programmable DC Power Supply (with Solar Array Simulation) 62000H Series
Operating & Programming Manual
3-38
V =
6 0
. 0 0 V I = 1 0. 0 0 _
A O F F
0 . 0 0 0 0 V 0 . 0 0 0 0
A
0
. 0
W
V _ L I M : 2 0 . 0 – 1 0 0 . 0 I_ L I M
: 2
.
0 0 –
1 8
. 0 0
Figure 3-62
When the selection is set to V/I /P PROTECT, the last line of the MAIN PAGE will show
the OVP, OCP and OPP settings in the PROTECTION as shown in Figure 3-63. See
sections 3.3.5.1 - 3.3.5.3 for a detailed description.
V = 6 0. 0 0 V I = 1 0. 0 0 _ A O F F
0 . 0 0 0 0 V 0 . 0 0 0 0 A
0 . 0 W
O V P = 6 6 0 . 0 V O C P = 1 8 . 9 0 A O P P = 1 0 5 0 0 . 0 W
Figure 3-63
When the selection is set to V/I SLEW, the last line on the MAIN PAGE will show the
settings of V SLEWRATE and I SLEWRATE in the OUTPUT SETUP as shown in Figure
3-64. See sections 3.3.2.3 and 3.3.2.4 for a detailed description
V = 6 0. 0 0 V I = 1 0. 0 0 _ A O F F
0 . 0 0 0 0 V 0 . 0 0 0 0 A
0 . 0 W
V _ S / R : 1 0 .0 0 0 ( V / m s ) I _ S / R : 0 . 0 0 1 ( A / m s )
Figure 3-64
