Circutor CVM-B100 User Manual

Table 22(Continuation):Units and maximum and minimum values of the programming variables of the
digital outputs.
Variable Units Maximum Minimum
Active Power
(3)
kW
180000
-180000
Apparent Power
(3)
kVA 0
Total Reactive Power
(3)
kvar -180000
Inductive Reactive Power
(3)
kvar 0
Capacitive Reactive Power
(3)
kvar
0
Power factor - 1.00 -1.00
Cos φ º 1.00 -1.00
Voltage THD % % 100.0 0
Current THD % % 100.0 0
Maximum Demand of
Current
A 10.000 *current ratio
(2)
0
Maximum Demand of
Active power
kW
180000 0
Maximum Demand of
Apparent Power
kVA
(1)
The voltage ratio is the ratio between the primary and secondary voltage.
(2)
The current ratio is the ratio between the primary and secondary current.
(3)
The three-phase powers accept up to 540000kW.
● When programming the connection delay (ON) of the relay digital output:
The connection delay is programmed in seconds.
, ... The ten possible digits to program.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the setup menu Figure 114.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
Connection delay (ON):
Maximum value: 999 s.
Minimum value: 0 s.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
150
CVM-B100 - CVM-B150
Instruction Manual
