● When programming the disconnection delay (OFF) of the relay digital output:
The disconnection delay is programmed in seconds.
, ... The ten possible digits to program.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the setup menu Figure 114.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
Disconnection delay (OFF):
Maximum value: 999 s.
Minimum value: 0 s.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
● When programming the output status of the relay:
Here you program the output status of the relay as normally closed or normally open.
Normally open.
Normally closed.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the setup menu Figure 114.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
151
Instruction Manual
CVM-B100 - CVM-B150
