The parameter selected is indicated in white.

The following options appear in the lower area:

● When programming the variable code which controls the transistor digital output (

Table 21):

, ... The ten possible digits to program.

Delete character, deletes the selected character.

Delete parameter, deletes the characters of the selected parameter.

Previous, selects the previous parameter.

Next, selects the next parameter.

Conrm, conrms and saves in the memory the values programmed on the screen.

Back, returns to the home screen of the setup menu Figure 114.

Main Menu, back to the main menu, Figure 25.

Use the keys

and to select the different options.

To conrm the selection, press the key

To cancel the operation of a digital output, the 00 code must be programmed.

If no key is pressed for 5 minutes, the display screen changes automatically to the default

screen.

● When programming the pre-alarm value:

If the unit exceeds the programmed pre-alarm value, the icon

is activated on the display,

and the icon that indicates the alarm status changes colour

The value is programmed in %.
