● When programming the minimum value below which the transistor is activated:
The units and maximum and minimum values of the variables to program are shown in Table
22
.
, ... The ten possible digits to program.
, Comma and minus sign.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the setup menu Figure 114.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
● When programming the maximum value above which the transistor is activated:
The units and maximum and minimum values of the variables to program are shown in
Table 22.
Note: The maximum value must be greater than the minimum value programmed.
, ... The ten possible digits to program.
, Comma and minus sign.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the setup menu Figure 114.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
155
Instruction Manual
CVM-B100 - CVM-B150
