● When programming the low period:

The low period is the time that the pulse is at its minimum value.

The programmed value is a multiple of 10 ms, i.e. when programming 1 the impulse will be at

its minimum value of 10 ms.

, ... The ten possible digits to program.

Delete character, deletes the selected character.

Delete parameter, deletes the characters of the selected parameter.

Previous, selects the previous parameter.

Next, selects the next parameter.

Conrm, conrms and saves in the memory the values programmed on the screen.

Back, returns to the home screen of the setup menu Figura 113.

Main Menu, back to the main menu, Figure 25.

Use the keys

and to select the different options.

To conrm the selection, press the key

Low period:

Maximum value: 65536.

Minimum value: 1.

If no key is pressed for 5 minutes, the display screen changes automatically to the default

screen.

● When programming the high period:

The high period is the time that the pulse is at its maximum value.

The programmed value is a multiple of 10 ms, i.e., when programming 1 the impulse will be at

its maximum value of 10 ms.
