● When programming the variable code which controls the transistor digital output (Table 21):
, ... The ten possible digits to program.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen
Back, returns to the home screen of the setup menu Figura 113.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
To cancel the operation of a digital output, the 00 code must be programmed.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
● When programming the energy meter factor:
The factor of the energy meter is the amount of energy per hour needed for generating a pulse,
in Wh.
, ... The ten possible digits to program.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the home screen of the setup menu Figura 113.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
159
Instruction Manual
CVM-B100 - CVM-B150
