5.6.17.3.- Conguration of digital inputs, logic state mode.
After selecting the conguration of an input in logic mode, you must select the input that you
want to congure in this mode:
Digital input 1.
Digital input 2.
When selecting the input to congure with the key
(Figure 137), you can program the input
logic.
Figure 137: Digital inputs conguration screen (logic state mode).
The parameter selected is indicated in white.
The following options appear in the lower area:
Positive, the digital input logic is positive.
Negative, the digital input logic is negative.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the main conguration screen for digital inputs Figure 134.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
166
CVM-B100 - CVM-B150
Instruction Manual
