If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
● When programming the MAC:
Here you have to program the MAC address.
, ... The ten possible digits to program.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Back, returns to the main conguration screen for integrated communications.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
Maximum value: 127.
Minimum value: 0.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
● When programming the Device ID:
, ... The ten possible digits to program.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the
screen
.
Delete character, deletes the selected character.
Delete parameter, deletes the characters of the selected parameter.
Back, returns to the main conguration screen for integrated communications.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
Maximum value: 4194303.
Minimum value: 0.
171
Instruction Manual
CVM-B100 - CVM-B150
