5.6.18.2.- Conguration parameters, BACnet protocol.
When selecting the BACnet communications protocol, Figure 139, you can program the
following parameters:
 The transmission speed, Baud Rate.
 The MAC.
 The Device ID.
Figure 139: Integrated communications conguration screen (BACnet protocol).
The parameter selected is indicated in white.
The following options appear in the lower area:
● When programming the transmission speed, Baud Rate:
, ... The possible transmission speeds: 9600, 19200, 38400, 57600, 76800
or 115200.
Previous, selects the previous parameter.
Next, selects the next parameter.
Confirm, confirms and saves in the memory the values programmed on the
screen.
Back, returns to the main conguration screen for integrated communications.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
170
CVM-B100 - CVM-B150
Instruction Manual
