If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
● When programming the parity:
Even parity.
Odd parity.
No parity.
Previous, selects the previous parameter.
Next, selects the next parameter.
Confirm, confirms and saves in the memory the values programmed on the
screen.
Back, returns to the main conguration screen for integrated communications.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
● When programming the number of stop bits:
, Possible numbers of stop bits: 1 or 2.
Previous, selects the previous parameter.
Next, selects the next parameter.
Conrm, conrms and saves in the memory the values programmed on the screen.
Back, returns to the main conguration screen for integrated communications.
Main Menu, back to the main menu, Figure 25.
Use the keys
and to select the different options.
To conrm the selection, press the key
.
If no key is pressed for 5 minutes, the display screen changes automatically to the default
screen.
