Table 79: Modbus memory map: Status of relay digital outputs (Table 2).
Status of relay digital outputs: Slot 1
Configuration variable
Address
Output
1
Output
2
Output
3
Output
4
Output
5
Output
6
Output
7
Output
8
Latch C670 C684 C698 C6AC C6C0 C6D4 C6E8 C6FC
Connection delay
C672 C686 C69A C6AE C6C2 C6D6 C6EA C6FE
Disconnection delay
C673 C687 C69B C6AF C6C3 C6D7 C6EB C6FF
Alarm activation date: Year C674 C688 C69C C6B0 C6C4 C6D8 C6EC C700
Alarm activation date: Month
C675 C689 C69D C6B1 C6C5 C6D9 C6ED C701
Alarm activation date: Day
C676 C68A C69E C6B2 C6C6 C6DA C6EE C702
Alarm activation time: Time C677 C68B C69F C6B3 C6C7 C6DB C6EF C703
Alarm activation time: Minutes C678 C68C C6A0 C6B4 C6C8 C6DC C6F0 C704
Alarm activation time: Seconds C679 C68D C6A1 C6B5 C6C9 C6DD C6F1 C705
Not used C67A C68E C6A2 C6B6 C6CA C6DE C6F2 C706
Not used C67B C68F C6A3 C6B7 C6CB C6DF C6F3 C707
Status C67C C690 C6A4 C6B8 C6CC C6E0 C6F4 C708
Alarm status C67D C691 C6A5 C6B9 C6CD C6E1 C6F5 C709
Note: The 14 registers must be read at once (as a group), otherwise it will respond with an
error.
Table 80: Modbus memory map: Status of relay digital outputs (Table 3).
Status of relay digital outputs: Slot 2
Configuration variable
Address
Output
1
Output
2
Output
3
Output
4
Output
5
Output
6
Output
7
Output
8
Latch CA58 CA6C CA80 CA94 CAA8 CABC CAD0 CAE4
Connection delay
CA5A CA6E CA82 CA96 CAAA CABE CAD2 CAE6
Disconnection delay
CA5B CA6F CA83 CA97 CAAB CABF CAD3 CAE7
Alarm activation date: Year CA5C CA70 CA84 CA98 CAAC CAC0 CAD4 CAE8
Alarm activation date: Month
CA5D CA71 CA85 CA99 CAAD CAC1 CAD5 CAE9
Alarm activation date: Day
CA5E CA72 CA86 CA9A CAAE CAC2 CAD6 CAEA
Alarm activation time: Time CA5F CA73 CA87 CA9B CAAF CAC3 CAD7 CAEB
Alarm activation time: Minutes CA60 CA74 CA88 CA9C CAB0 CAC4 CAD8 CAEC
Alarm activation time: Seconds CA61 CA75 CA89 CA9D CAB1 CAC5 CAD9 CAED
Not used CA62 CA76 CA8A CA9E CAB2 CAC6 CADA CAEE
Not used CA63 CA77 CA8B CA9F CAB3 CAC7 CADB CAEF
Status CA64 CA78 CA8C CAA0 CAB4 CAC8 CADC CAF0
Alarm status CA65 CA79 CA8D CAA1 CAB5 CAC9 CADD CAF1
Note: The 14 registers must be read at once (as a group), otherwise it will respond with an
error.
225
Instruction Manual
CVM-B100 - CVM-B150
