7.3.4.4.- Status of digital inputs
The following functions are implemented for these variables:
Function 0x04: reading registers.
Table 100: Modbus memory map: Status of digital inputs (Table 1).
Status of digital inputs: Slot 1
Configuration variable Address Valid data window
Input Status 1 C5A8 – C5A9 0 to 1
Input Status 2 C5AA – C5AB 0 to 1
Input Status 3 C5AC – C5AD 0 to 1
Input Status 4 C5AE – C5AF 0 to 1
Input Status 5 C5B0 – C5B1 0 to 1
Input Status 6 C5B2 – C5B3 0 to 1
Input Status 7 C5B4 – C5B5 0 to 1
Input Status 8 C5B6 – C5B7 0 to 1
Table 101: Modbus memory map: Status of digital inputs (Table 2).
Status of digital inputs: Slot 2
Configuration variable Address Valid data window
Input Status 1 C990 – C991 0 to 1
Input Status 2 C992 – C993 0 to 1
Input Status 3 C994 – C995 0 to 1
Input Status 4 C996 – C997 0 to 1
Input Status 5 C998 – C999 0 to 1
Input Status 6 C99A – C99B 0 to 1
Input Status 7 C99C – C99D 0 to 1
Input Status 8 C99E – C99F 0 to 1
Table 102: Modbus memory map: Status of digital inputs (Table 3).
Status of digital inputs: Slot 3
Configuration variable Address Valid data window
Input Status 1 CD78 - CD79 0 to 1
Input Status 2 CD7A - CD7B 0 to 1
Input Status 3 CD7C - CD7D 0 to 1
Input Status 4 CD7E - CD7F 0 to 1
Input Status 5 CD80 - CD81 0 to 1
Input Status 6 CD82 - CD83 0 to 1
Input Status 7 CD84 - CD85 0 to 1
Input Status 8 CD86 - CD87 0 to 1
