Table 97:Modbus memory map: Digital inputs, expansion modules (Table 3).

Conguration of digital inputs: Slot 2

Configuration variable

Address

Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8

Mode

C8C8

C8D4 C8E0 C8EC C8F8 C904 C910 C91C

Logic (Logic state)

C8C9

C8D5 C8E1 C8ED C8F9 C905 C911 C91D

No. of decimals (Impulses) C8CA

C8D6 C8E2 C8EE C8FA C906 C912 C91E

Not used

C8CB

C8D7 C8E3 C8EF C8FB C907 C913 C91F

Input name (impulses)

C8CC-

C8CF

C8D8-

C8DB

C8E4-

C8E7

C8F0-

C8F3

C8FC-

C8FF

C908-

C90B

C914-

C917

C920-

C923

Units (Impulses)

C8D0-

C8D2

C8DC-

C8DE

C8E8-

C8EA

C8F4-

C8F6

C900-

C902

C90C-

C90E

C918-

C91A

C924-

C926

Note: The 11 registers must be written and read at once (as a group), otherwise it will respond

with an error.

Table 98:Modbus memory map: Digital inputs, expansion modules (Table 4).

Conguration of digital inputs: Slot 3

Configuration variable

Address

Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8

Mode

CCB0

CCBC CCC8 CCD4 CCE0 CCEC CCF8 CD04

Logic (Logic state)

CCB1

CCBD CCC9 CCD5 CCE1 CCED CCF9 CD05

No. of decimals (Impulses) CCB2

CCBE CCCA CCD6 CCE2 CCEE CCFA CD06

Not used

CCB3

CCBF CCCB CCD7 CCE3 CCEF CCFB CD07

Input name (impulses)

CCB4 -

CCB7

CCC0 -

CCC3

CCCC -

CCCF

CCD8-

CCDB

CCE4-

CCE7

CCF0-

CCF3

CCFC-

CCFF

CD08-

CD0B

Units (Impulses)

CCB8 -

CCBA

CCC4 -

CCC6

CCD0 -

CCD2

CCDC-

CCDE

CCE8-

CCEA

CCF4-

CCF6

CD00-

CD02

CD0C-

CD0E

Note: The 11 registers must be written and read at once (as a group), otherwise it will respond

with an error.

Table 99:Modbus memory map: Digital inputs, expansion modules (Table 5).

Conguration of digital inputs: Slot 4

Configuration variable

Address

Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Input 7 Input 8

Mode

D098

D0A4 D0B0 D0BC D0C8 D0D4 D0E0 D0EC

Logic (Logic state)

D099

D0A5 D0B1 D0BD D0C9 D0D5 D0E1 D0ED

No. of decimals (Impulses) D09A

D0A6 D0B2 D0BE D0CA D0D6 D0E2 D0EE

Not used

D09B

D0A7 D0B3 D0BF D0CB D0D7 D0E3 D0EF

Input name (impulses)

D09C-

D09F

D0A8-

D0AB

D0B4-

D0B7

D0C0-

D0C3

D0CC-

D0CF

D0D8-

D0DB

D0E4-

D0E7

D0F0-

D0F3

Units (Impulses)

D0A0-

D0A2

D0AC-

D0AD

D0B8-

D0BA

D0C4-

D0C6

D0D0-

D0D2

D0DC-

D0DE

D0E8-

D0EA

D0F4-

D0F6

Note: The 11 registers must be written and read at once (as a group), otherwise it will respond

with an error.

237
