Circutor CVM-B100 User Manual

Variable Name Variable type Unit
Current THD L2
nvo_THDVal_I2 SNVT_lev_percent (81) THD A% L2
Code Resolution Values
29 0.005 -163.840..163.830
Current THD L3
Name Variable type Unit
nvo_THDVal_I3 SNVT_lev_percent (81) THD A% L3
Code Resolution Values
30 0.005 -163.840..163.830
Voltage THD L1
Name Variable type Unit
nvo_THDVal_U1 SNVT_lev_percent (81) THD V% L1
Code Resolution Values
25 0.005 -163.840..163.830
Voltage THD L2
Name Variable type Unit
nvo_THDVal_U2 SNVT_lev_percent (81) THD V% L2
Code Resolution Values
26 0.005 -163.840..163.830
Voltage THD L3
Name Variable type Unit
nvo_THDVal_U3 SNVT_lev_percent (81) THD V% L3
Code Resolution Values
27 0.005 -163.840..163.830
Neutral current
Name Variable type Unit
nvo_neutralCurrent SNVT_amp_ac (139) In
Code Resolution Values
32 1 0..65,534
Active power III
Name Variable type Unit
nvo_ActPwOn3Ph SNVT_power_kilo (28) kW III
Code Resolution Values
16 0.1 0..6553.5
Inductive Reactive Power III
Name Variable type Unit
nvoInductPwOn3Ph SNVT_power_kilo (28) kVArL III
Code Resolution Values
17 0.1 0..6553.5
Capacitive Reactive Power III
Name Variable type Unit
nvo_CapPwOn3Ph SNVT_power_kilo (28) kVArC III
Code Resolution Values
18 0.1 0..6553.5
Apparent Power III
Name Variable type Unit
nvo_AppPwOn3Ph SNVT_power_kilo (28) kVA III
Code Resolution Values
36 0.1 0..6553.5
Power Factor III
Name Variable type Unit
nvo_PwFactOn3Ph SNVT_pwr_fact (98) PF III
Code Resolution Values
20 0.00005 -1.00000..1.00000
Cos φ III
Name Variable type Unit
nvo_Cosphi SNVT_pwr_fact (98) cos φ
Code Resolution Values
19 0.00005 -1.00000..1.00000
274
CVM-B100 - CVM-B150
Instruction Manual
