Variable Name Variable type Unit
Three-phase Current
nvoAvgValCurr3Ph SNVT_amp_ac (139) I_AVG
Code Resolution Values
31 1 0..65,534
Current Maximum Demand L1
Name Variable type Unit
nvo_MaxDemand_A1 SNVT_amp_ac (139) Md(A1)
Code Resolution Values
37 1 0..65,534
Current Maximum Demand L2
Name Variable type Unit
nvo_MaxDemand_A2 SNVT_amp_ac (139) Md(A2)
Code Resolution Values
38 1 0..65,534
Current Maximum Demand L3
Name Variable type Unit
nvo_MaxDemand_A3 SNVT_amp_ac (139) Md(A3)
Code Resolution Values
39 1 0..65,534
Md Current III
Name Variable type Unit
nvo_MaxDemand_A SNVT_amp_ac (139) Md(A III)
Code Resolution Values
40 1 0..65,534
Md Active Power III
Name Variable type Unit
nvo_MaxDemand_kw SNVT_power_kilo (28) Md(kW III)
Code Resolution Values
41 0.1 0..6553.5
Md Apparent Power III
Name Variable type Unit
nvo_MaxDemand_kVA SNVT_power_kilo (28) Md(kVA III)
Code Resolution Values
42 0.1 0..6553.5
Active Energy (+)
Name Variable type Unit
nvo_ActEnergy SNVT_elec_kwh_I (146) kW.h(+)
Code Resolution Values
43 0.1 -214,748,364.8.. 214,748,364.6
Inductive Reactive Energy (+)
Name Variable type Unit
nvo_InductEnergy SNVT_elec_kwh_I (146) kVArL.h(+)
Code Resolution Values
44 0.1 -214,748,364.8.. 214,748,364.6
Capacitive Reactive Energy (+)
Name Variable type Unit
nvo_CapEnergy SNVT_elec_kwh_I (146) kVArC.h(+)
Code Resolution Values
45 0.1 -214,748,364.8.. 214,748,364.6
Apparent Energy (+)
Name Variable type Unit
nvo_AppEnergy SNVT_elec_kwh_I (146) kVA.h(+)
Code Resolution Values
46 0.1 -214,748,364.8.. 214,748,364.6
Active Energy (-)
Name Variable type Unit
nvoActEnergy_exp SNVT_elec_kwh_I (146) kW.h(-)
Code Resolution Values
47 0.1 -214,748,364.8.. 214,748,364.6
275
Instruction Manual
CVM-B100 - CVM-B150
