Arrray 3 tipo NVT ( SNVT_str_int (37)), Unit (N/A), Resolution (1), Values (0...65,565), Bytes (31)

typedef struct {

unsigned short char_set ;

unsigned long wide_char [15] ;

} SNTV_str_int;

Name Variable type Unit

Active Energy (+)

nvo_ActEnergy SNVT_elec_kwh_I (146) kW.h(+)

Code Resolution Values

43 0.1 -214,748,364.8.. 214,748,364.6

Inductive Reactive Energy (+)

Name Variable type Unit

nvo_InductEnergy SNVT_elec_kwh_I (146) kVArL.h(+)

Code Resolution Values

44 0.1 -214,748,364.8.. 214,748,364.6

Notes:

 All the variables declared in the arrays are shown without a sign.

 All the power variables (SNVT_power_kilo type) are shown without a sign.

 There is a variable called nvi_UpdatePeriod that indicates the refresh time of the varia-

bles linked with bindings. It is a NVT type variable (SNVT_time_sec (107), Units (Seconds),

Resolution(0.1s), Values (5.0 ... 3200.0), Bytes (2)).

 All of the instantaneous variables listed in this section have a maximum value (_M) and

minimum (_m) value, adding the displayed structures behind the name of the variable. For

example, the maximum value of the L1 current is nvo_Ph1Current_M and minimum value is

nvo_Ph1Current_m.

279

Instruction Manual

CVM-B100 - CVM-B150
