Module 5
Table 147: GSD modules (Module 5)
Mod 5
THD V / I Symbol Bytes Address Units
V 1 THD ratio THDV1 4 4E-4F %x100
V 2 THD ratio THDV2 4 50-51 %x100
V 3 THD ratio THDV3 4 52-53 %x100
V N THD ratio THDVN 4 54-55 %x100
I 1 THD ratio THDI1 4 56-57 %x100
I 2 THD ratio THDI2 4 58-59 %x100
I 3 THD ratio THDI3 4 5A-5B %x100
IN THD ratio THDIN 4 5C-5D %x100
Module 8
Table 148: GSD modules (Module 8)
Mod 8
Odd harmonics voltage Symbol Bytes Address Units
L 1
Fundamental Harm. V1_fund 4 0A28-0A29 Vx100
3rd Order Harmonic v1 H3 2 0A2B %x100
5th Order Harmonic v1 H5 2 0A2D %x100
7th Order Harmonic v1 H7 2 0A2F %x100
9th Order Harmonic v1 H9 2 0A31 %x100
11th Order Harmonic v1 H11 2 0A33 %x100
13th Order Harmonic v1 H13 2 0A35 %x100
15th Order Harmonic v1 H15 2 0A37 %x100
L 2
Fundamental Harm. V2_fund 4 0A5B-0A5C Vx100
3rd Order Harmonic v2 H3 2 0A5E %x100
5th Order Harmonic v2 H5 2 0A60 %x100
7th Order Harmonic v2 H7 2 0A62 %x100
9th Order Harmonic v2 H9 2 0A64 %x100
11th Order Harmonic v2 H11 2 0A66 %x100
13th Order Harmonic v2 H13 2 0A68 %x100
15th Order Harmonic v2 H15 2 0A6A %x100
L3
Fundamental Harm. V3_fund 4 0A8E-0A8F Vx100
3rd Order Harmonic v3 H3 2 0A91 %x100
5th Order Harmonic v3 H5 2 0A93 %x100
7th Order Harmonic v3 H7 2 0A95 %x100
9th Order Harmonic v3 H9 2 0A97 %x100
11th Order Harmonic v3 H11 2 0A99 %x100
13th Order Harmonic v3 H13 2 0A9B %x100
15th Order Harmonic v3 H15 2 0A9D %x100
N
Fundamental Harm. Vn_fund 4 0AC1-0AC2 Vx100
3rd Order Harmonic vn H3 2 0AC4 %x100
5th Order Harmonic vn H5 2 0AC6 %x100
287
Instruction Manual
CVM-B100 - CVM-B150
