Module 3
Table 143: GSD modules (Module 3 - Mod 3.1)
Mod 3.1
Average values Symbol Bytes Address Units
Average phase voltage Vn_AVG 4 3C-3D Vx100
Average line voltage Vp_AVG 4 3E-3F Vx100
Average current I_AVG 4 40-41 mA
Table 144: GSD modules (Module 3 - Mod 3.2)
Mod 3.2
Neutral values Symbol Bytes Address Units
Neutral voltage Vn 4 30-31 Vx100
Neutral current In 4 32-33 mA
Current A 3 4 22-23 mA
Table 145: GSD modules (Module 3 - Mod 3.3)
Mod 3.3
Three-phase values Symbol Bytes Address Units
Three-phase active power Kw III 4 42-43 W
Three-phase inductive power KvarL III 4 44-45 var
Three-phase capacitive power KvarC III 4 46-47 var
Three-phase apparent power KvaIII 4 48-49 VA
Three-phase power factor PFIII 4 4A-4B x100
Cos φ three-phase Cos φ III 4 4C-4D x100
Module 4
Table 146: GSD modules (Module 4)
Mod 4
Total tariff Symbol Bytes
Address
kWh
Address
Wh
Units
Tariff 1
Active Energy kwh III 4 500-501 kWh
Active Energy wh III 2 502 Wh
Inductive Reactive Energy kvarhL III 4 503-504 kWh
Inductive Reactive Energy varhL III 2 505 Wh
Capacitive reactive energy kvarhC III 4 506-507 kWh
Capacitive reactive energy varhC III 2 508 Wh
Three-phase apparent energy kVAh III 4 509-50A kWh
Three-phase apparent energy VAh III 2 50B Wh
Generated active energy kWhIII (-) 4 50C-50D kWh
Generated active energy WhIII (-) 2 50E Wh
Inductive active energy kvarLhIII (-) 4 50F-510 kWh
Inductive active energy varLhIII (-) 2 511 Wh
Inductive active energy kvarChIII (-) 4 512-513 kWh
Inductive active energy varChIII (-) 2 514 Wh
Generated apparent energy kVAhIII (-) 4 515-516 kWh
Generated apparent energy VAhIII (-) 2 517 Wh
286
