● For the Active tariff time, CO
2
Emissions
and
Cost parameters:
Phase L1.
The tariff must be selected after selecting the phase:
Tariff 1, Tariff 2, Tariff 3, Total tariff.
And to select the consumption or generation value:
Consumption, Generation.
Finally, the option appears for saving the selection.
The following options are also shown on the bottom at all times
Back, returns to the previous customisation screen.
Main Menu, back to the main menu, Figure 25.
Use the keys and to browse the different options.
To access the option selected press the key
.
5.1.1.2.1.1.3.-
Selecting a demand parameter.
Figure 49 shows the screen for selecting a demand parameter.
Figure 49: Custom parameters screen, selecting a demand parameter (displays 1 parameter).
The menu in the lower area disappears after 3 seconds.
61
Instruction Manual
CVM-B100 - CVM-B150
