Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring EtherChannels and Link-State Tracking
Configuring EtherChannels
For more information about switch stacks, see Chapter 1, “Managing Switch Stacks.”
Configuring EtherChannels
These sections contain this configuration information:
• Default EtherChannel Configuration, page 1-11
• EtherChannel Configuration Guidelines, page 1-12
• Configuring Layer 2 EtherChannels, page 1-13 (required)
• Configuring Layer 3 EtherChannels, page 1-15 (required)
• Configuring EtherChannel Load-Balancing, page 1-18 (optional)
• Configuring the PAgP Learn Method and Priority, page 1-19 (optional)
• Configuring LACP Hot-Standby Ports, page 1-20 (optional)
Note Make sure that the ports are correctly configured. For more information, see the “EtherChannel
Configuration Guidelines” section on page 1-12.
Note After you configure an EtherChannel, configuration changes applied to the port-channel interface apply
to all the physical ports assigned to the port-channel interface, and configuration changes applied to the
physical port affect only the port where you apply the configuration.
Default EtherChannel Configuration
Table 1-3 Default EtherChannel Configuration
Feature Default Setting
Channel groups None assigned.
Port-channel logical interface None defined.
PAgP mode No default.
PAgP learn method Aggregate-port learning on all ports.
PAgP priority 128 on all ports.
LACP mode No default.
LACP learn method Aggregate-port learning on all ports.
LACP port priority 32768 on all ports.
LACP system priority 32768.
LACP system ID LACP system priority and the switch or stack MAC
address.
Load-balancing Load distribution on the switch is based on the
source-MAC address of the incoming packet.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
