1-12
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring System Message Logging and Smart Logging
Configuring System Message Logging
Beginning in privileged EXEC mode, follow these steps to enable configuration logging:
This example shows how to enable the configuration-change logger and to set the number of entries in
the log to 500.
Switch(config)# archive
Switch(config-archive)# log config
Switch(config-archive-log-cfg)# logging enable
Switch(config-archive-log-cfg)# logging size 500
Switch(config-archive-log-cfg)# end
This is an example of output for the configuration log:
Switch# show archive log config all
idx sess user@line Logged command
38 11 unknown user@vty3 |no aaa authorization config-commands
39 12 unknown user@vty3 |no aaa authorization network default group radius
40 12 unknown user@vty3 |no aaa accounting dot1x default start-stop group
radius
41 13 unknown user@vty3 |no aaa accounting system default
42 14 temi@vty4 |interface GigabitEthernet4/0/1
43 14 temi@vty4 | switchport mode trunk
44 14 temi@vty4 | exit
45 16 temi@vty5 |interface GigabitEthernet5/0/1
46 16 temi@vty5 | switchport mode trunk
47 16 temi@vty5 | exit
Configuring UNIX Syslog Servers
The next sections describe how to configure the UNIX server syslog daemon and how to define the UNIX
system logging facility.
Logging Messages to a UNIX Syslog Daemon
Before you can send system log messages to a UNIX syslog server, you must configure the syslog
daemon on a UNIX server. This procedure is optional.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
archive Enter archive configuration mode.
Step 3
log config Enter configuration-change logger configuration mode.
Step 4
logging enable Enable configuration change logging.
Step 5
logging size entries (Optional) Configure the number of entries retained in the configuration
log. The range is from 1 to 1000. The default is 100.
Note When the configuration log is full, the oldest log entry is removed
each time a new entry is entered.
Step 6
end Return to privileged EXEC mode.
Step 7
show archive log config Verify your entries by viewing the configuration log.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
